MADSci Clients

Provides a collection of clients for interacting with the different components of a MADSci interface.

Installation¶

See the main README for installation options. This package is available as:

• PyPI: pip install madsci.client

• Docker: Included in ghcr.io/ad-sdl/madsci

• Dependency: Required by most other MADSci packages

Node Clients¶

Node clients provide a robust interface for interacting with MADSci Nodes:

• Action execution: Send actions with automatic parameter serialization and result handling

• Node introspection: Get detailed node information, capabilities, and schemas

• State monitoring: Monitor current state and status with real-time updates

• Administrative control: Send commands (safety stop, pause, resume, etc.)

• Error handling: Comprehensive error reporting and retry mechanisms

• File operations: Seamless file upload/download support

Multiple communication protocols are supported through a common interface. The AbstractNodeClient base class enables custom protocol implementations.

REST Client¶

Communicate with MADSci Nodes via REST API with enhanced argument handling:

from madsci.client.node.rest_node_client import RestNodeClient
from madsci.common.types.action_types import ActionRequest
from pathlib import Path

client = RestNodeClient(url="http://example:2000")

# Simple action execution
action_request = ActionRequest(action_name="get_temperature", args={}, files={})
result = client.send_action(action_request)

# Action with parameters (automatically serialized)
action_request = ActionRequest(
    action_name="analyze_sample",
    args={"sample_id": "sample_001", "duration": 60, "temperature": 25.0},
    files={}
)
result = client.send_action(action_request)

# File upload handling
action_request = ActionRequest(
    action_name="process_file",
    args={"output_dir": "./results"},
    files={"input_file": Path("./data.csv")}
)
result = client.send_action(action_request)

# Get comprehensive node info
info = client.get_info()
status = client.get_status()

Key Features:

• Automatic parameter validation and serialization

• File upload/download handling with progress tracking

• Comprehensive error messages and debugging information

• Support for complex return types (JSON, files, datapoint IDs)

• Node capability checking and schema introspection

Examples: See example_lab/notebooks/node_notebook.ipynb for detailed usage.

Event Client¶

Allows a user or system to interface with a MADSci EventManager, or log events locally if one isn’t available/configured. Can be used to both log new events and query logged events.

For detailed documentation on usage, see the EventManager Documentation.

Experiment Application¶

The ExperimentApplication class is a helper class designed to act as scaffolding for a user’s own python experiment. It provides helpful tooling around tracking and responding to changes in Experiment status, marshalling the clients needed to leverage different parts of a MADSci-enabled lab, and implementing your own custom experimental logic.

Experiment Client¶

Allows the user or an automated system/agent to inerface with a MADSci ExperimentManager to capture Experiment Designs and track status and metadata related to specific Experimental Runs and whole Experimental Campaigns.

For detailed documentation on usage, see the ExperimentManager Documentation

Data Client¶

Allows the user or an automated system/agent to interface with a MADSci DataManager to upload, query, and fetch DataPoints. Currently supports ValueDataPoints (which can include any JSON-serializable data) and FileDataPoints (which directly stores the files).

Enhanced Datapoint Operations¶

The Data Client provides comprehensive methods for working with datapoints in workflows:

from madsci.client.data_client import DataClient

client = DataClient()

# Upload value datapoints
datapoint_id = client.submit_datapoint({
    "label": "experiment_result",
    "value": {"temperature": 25.0, "pressure": 1.2}
})

# Upload file datapoints
file_datapoint_id = client.submit_file_datapoint(
    file_path=Path("./results.csv"),
    label="analysis_results"
)

# Batch fetch multiple datapoints efficiently
datapoints = client.get_datapoints_by_ids(["id1", "id2", "id3"])

# Query datapoints with filters
results = client.query_datapoints(
    label_pattern="experiment_*",
    limit=10
)

# Get lightweight metadata without loading full data
metadata = client.get_datapoint_metadata("datapoint_id")

The Data Client integrates seamlessly with the workflow system, storing only ULID strings in workflows for optimal performance while providing easy access to full datapoint objects when needed.

Integration with Workflows:

# Workflow helper methods
from madsci.client.workcell_client import WorkcellClient

workcell = WorkcellClient()
workflow = workcell.submit_workflow("analysis.yaml")

# Get datapoint from workflow step
datapoint_id = workflow.get_datapoint_id("analysis_step")
datapoint = workflow.get_datapoint("analysis_step")

For detailed documentation on usage, see the DataManager Documentation.

Resource Client¶

Allows the user or an automated system/agent to interface with a MADSci ResourceManager to initialize, manage, track, query, update, and remove physical resources (including samples, consumables, containers, labware, etc.).

For detailed documentation on usage, see the ResourceManager Documentation.

Workcell Client¶

Allows the user or an automated system/agent to interface with a MADSci WorkcellManager. Includes support for submitting, querying, and controlling Workflows, sending admin commands to the Workcell, and interacting with Workcell Locations.

For detailed documentation on usage, see the WorkcellManager Documentation.
